Chilworth 17x27 Handcrafted Clay Plain Tile

Our aim is to preserve your local heritage, so we have created our 17x27 handcrafted Chilworth plain tile, ideal for all historic and traditional roofing projects.

Chilworth Handmade

Traditional firing over a wood fire: In following tradition, we offer you a tile to create your own authentic style. After grinding and extruding the clay, the tiles are dried with wood bark and then fired with sawdust.

A distressed surface and tail: An irregular effect to reinforce the aesthetic appearance of tiles eroded over time with a variable granular deposit on the surface.

Variable tile length: Each tile has a slightly different length to reflect the irregularly of old roofs. Our unique cutting system enables 50% of tiles to vary in length by 1cm.


Technical data

Quantity per pallet:
720 tiles

Max Batten Gauge:
100mm

Number per m2:
60mm

Gauge of 100mm:
60mm

Tile Weight:
138kg

Thickness:
12.5mm

Overall dimension:
275 x 170mm

Coverage per m²:
Between 53 and 58.5 tiles

Nominal gauge:
From 95 mm to 105 mm

Linear metres of battens per m2 of roof:
From 9.52 ml to 10.53 ml

Working width:
180m

Unit weight:
1.60kg

Features

This manufacturing process uses 100% green energy.  We use traditional firing techniques, with a wood fire, to create unrivalled blends of colours and hues within each batch. Tiles are fired at an average temperature of 1000° for 2 days, with subtle variations depending on the position of tiles within the kiln ensuring each tile is unique in shape and finish. With its Vézère colour, this new tile perfectly matches local English Heritage.

Discover the Vézère colour, in red and brown tones, with its crafted irregular surface finishes, to perfectly display the authentic and timeless appeal of traditional English roofs. If you’re looking to match with the local English heritage, 17X27 HANDCRAFTED CHILWORTH PLAIN TILES are the perfect solution. We offer you traditionally made clay tiles but fired in modern kilns for durability.

Our focus on skills with tradition and undeniable expertise in manufacturing guarantee unrivalled beauty blending seamlessly with the local vernacular. We understand your requirements and want to work with you to produce an exceptional roof.

  • A Distressed Surface and Tail
  • A Format Adapted for Ancient Roofing
  • Variable Tile Length
  • Strong and Durable
  • Traditional Appearance
  • Natural Product (Silicone Free)
  • Free Technical Support


Installation

All tiles, fittings & accessories should be installed in accordance with the recommendations given in BS5534: the British Standard Code of practice for slating & tiling. Sitework should be carried out in accordance with BS 8000-6: the British Standard for workmanship on building sites. Contact RDUK for technical support including estimates and fixing specification.
