Beauvoise Graphite Clay Slate
The Beauvoise Graphite tile is timeless, its shape is sober yet contemporary; its colour is authentic yet ageless and its terracotta tile qualities make it a roofing product suited to all kinds of buildings, new-build and in restoration. It also reduced labour costs will also increase this differential considerably due to no on-site grading requirements.
Manufacturing Standards
Edilians tiles fully comply with the requirements of BS EN 1304; the European Standard for clay tiles & fittings & are manufactured under a Quality Management system certified to comply with ISO 9001.
Technical data
Quantity per pallet:
480 tiles
Coverage at 245mm gauge:
20.5 tiles per m2
Nominal batten gauge*:
245mm
Overall length:
322mm
Overall width:
235mm
Cover width:
200mm
Head lap:
77mm
Weight per tile:
1.9kg
Weight per m2 at maximum gauge:
39kg
Minimum roof pitch:
22.0°
Batten coverage m2:
4.08m
Batten sizes:
38 x 25mm for rafter centres up to 450mm.
50 x 25mm for rafter centres up to 600mm.
Tile nail:
50 x 3.35mm aluminium clout head
* Always check each batch of tiles delivered to site to determine the actual gauge, which may vary slightly due to drying and firing shrinkage during the manufacturing process
Features
The elegant of slate, the purity of terracotta
The Beauvoise Graphite tile is a blend of the best of its origins: the historic clay of Beauvais and the sleek, polished look of slate. These small-format plain interlocking tiles are without a doubt a new classic in contemporary roof style.
The charm of slate
Increasingly used both in the roofing and to dress the facades of cladding, the good looks of natural slate never fail to please. As a solutions specialist for roofs and facades, EDILIANS has extended its small mould range to offer a terracotta tile with the look of a natural slate.
The merits of the terracotta tile
Made of Beauvais clay, the Beauvoise Graphite Terracotta tile retains the pure lines and straight front edge of the Beauvoise Huguenot tile, whose mould was used in its design. With its slightly finer profile, slate grey colour and textured surface, it creates a perfect imitation of natural slate roofs, at a much lower cost per square metre, while retaining the undeniable advantages of terracotta roofing.
- Authentic natural slate appearance
- Riven surface with dressed leading edges
- Suitable for both new build and restoration projects
- Cost-effective alternative to natural slate
- Natural Product (Silicone Free)
- 30-year durability guarantee
Installation
All tiles, fittings & accessories should be installed in accordance with the recommendations given in BS 5534: the British Standard Code of practice for slating & tiling. Sitework should be carried out in accordance with BS 8000-6: the British Standard for workmanship on building sites. Contact Edilians Technical Support for projects where the rafter length exceeds 6 metres.
