Single Panne S Traditional Clay Pantile

Technical data

Quantity per pallet:
420 tiles

Coverage:
20.0 tiles per m2

Batten gauge*:
275mm

Overall length:
342mm

Overall width:
232mm

Cover width:
190mm

Head lap:
64mm

Weight per tile:
2.3kg

Weight per m2 at maximum gauge:
46.0kg

Minimum roof pitch:
22.5°

Batten coverage per m2:
3.63m

Batten sizes:
38 x 25mm for rafter centres up to 450mm.
50 x 25 mm for rafter centres up to 600mm.

Tile nail:
50 x 3.35mm aluminium clout head

 * Always check each batch of tiles delivered to site to determine the actual gauge, which may vary slightly due to drying and fi ring shrinkage during the manufacturing process

Features

A classic
It's a traditional Flemish Panne tile with a pleasing profile. Its good looks are typical of roofs in the North at Pas-de-Calais or the Somme. Which had a major influence on roofing during the 18th century along the eastern coastline in the UK with "old English pantiles" which our single Panne S continues to emulate today.

Modern techniques
When developing new products, we always look to combine ease and rapidity of installation with a high level of water tightness which can be installed at roof pitches as low as 22.5°.

For newbuild and renovation
With an appropriate range of accessories, it will soon become a reference point for both newbuild and renovation. A large range of colours means it will fit perfectly into your surroundings. The range of accessories is also compatible with the related Double Panne S.

• Attractive modular size
• Extensive range of colours
• Ideal for renovation and new build
• Compatible with EDILIANS PV Modules
• Natural Product (Silicone Free)
• 30 Year Guarantee

Installation
All tiles, fittings & accessories should be installed in accordance with the recommendations given in BS 5534: the British Standard Code of practice for slating & tiling. Sitework should be carried out in accordance with BS 8000-6: the British Standard for workmanship on building sites. Contact Edilians Technical Support for projects where the rafter length exceeds 6 metres.

Colours

Natural Red

Rustic Red

Burnt Red

Old Vintage

Vieux Nord

Slate

Satin Black
