Clay Plain Tile - Single Camber 265mm x 165mm

A high-quality clay plain tile allows the creation of traditional and contemporary low-pitch designs with the warmth and character of the clay.

Clay Plain Tile - Single Camber
The Roofing Distribution UK single camber is a non-interlocking clay plain tile available in a range of colours including Natural Red, Toscana, Dark Rustic and Matt Black, more colours are being developed. We manufacture a wide selection of clay plain roof tile fittings and accessories, single camber clay plain roofing tile fittings and accessories are available in a selection of colours designed to match your roof.

Manufacturing Standards
This traditional shaped roof tile is manufactured to the highest standard using only the best raw materials available. The most modern technologies at our Schermbecker factory ensure that this profile is precise in its shape enabling the roof tilers to provide a high-quality finished roof. Whatever your needs, our clay plain single camber tiles are available with a wide choice of fittings and accessories all proven to complement any type of project.

Technical data

Size of tile:
265mm x 165mm

Minimum pitch*:

Maximum pitch:

Minimum headlap:
65mm (roof) - 35mm (vertical)

Maximum gauge:
100mm (roof) - 115mm (vertical)

Cover width:
165mm (nominal)

Tile thickness:
11mm (nominal)

Covering capacity:
60 tiles/m2 at 100mm gauge (roof)
(net): 53 tiles/m2 at 115mm gauge (vertical)

Weight of tiling:
64kg/m2 (0.63 kN/m2) at 100mm gauge (roof)
(approx.): 56kg/m2 (0.55 kN/m2) at 115mm gauge (vertical)

Battens required:
10.0 lin.m/m2 at 100mm gauge (roof)
(net): 8.7 lin.m/m2 at 115mm gauge (vertical)

Batten size:
38 x 25mm for rafters/supports not exceeding 600mm
recommended: centres (fixed to BS 5534)

Tile nails:
38mm x 2.65mm

BS EN 1304

 * The minimum recommended pitch and lap may be influenced by special circumstances, please contact the Technical Advisory Service.


  • High-quality clay
  • Minimum roof pitch 30°
  • Long term durability
  • Eco friendly
  • Low maintenance
  • Wide range of fittings
  • Quick, easy & secure installation

All tiles, fittings & accessories should be installed in accordance with the recommendations given in BS 5534: the British Standard Code of practice for slating & tiling. Sitework should be carried out in accordance with BS 8000-6: the British Standard for workmanship on building sites. Contact RDUK for technical support including estimates and fixing specifications.

30 year manufacturer's guarantee
Schermbecker Building Products clay tile collection is guaranteed for a minimum of 30 years from the date of supply, subject to the company's normal terms of guarantee and conditions and also provided that they have been installed in accordance with BS 5534 & BS 8000-6.

All sizes are approx. Tolerances according to DIN EN 1304.
Covering sizes are to be determined on-site. Subject to technical changes. Site-specific fixing specifications are available on request.
Please note: Mix tiles from at least 3 different pallets of tiles when loading out.


Natural Red


Dark Rustic

Matt Black
