Double Panne S Traditional Clay Pantile

Technical data

Quantity per pallet:
210 tiles

Coverage at 275mm gauge:
10.0 tiles per m2

Nominal batten gauge*:
275mm

Overall length:
339mm

Overall width:
423mm

Cover width:
378mm

Minimum head lap:
64mm

Weight per tile:
4.3kg

Weight per m2 at maximum gauge:
43.0kg

Minimum roof pitch:
17.5°

Batten coverage per m2:
3.63m

Batten sizes:
38 x 25mm for rafter centres up to 450mm.
50 x 25 mm for rafter centres up to 600mm.

Tile nail:
50 x 3.35mm aluminium clout head

 * Always check each batch of tiles delivered to site to determine the actual gauge, which may vary slightly due to drying and fi ring shrinkage during the manufacturing process

Features

An innovative tile
Made at Wardrecques, this tile has an unrivalled installation time and very high-quality coatings.

Extra-wide
This 2 in 1 tile will improve your installation time considerably whilst retaining that regional appearance. This Double Panne S is from the same family as the Panne S with which it shares the same range of accessories.

Proven strength
Particular attention has been paid to the choice of coatings in order to guarantee optimum resistance to impact.

• Economical 10m² coverage
• Low roof pitch suitability (17.5°)
• Quick and easy to install
• 30 Year durability guarantee
• Natural Product (Silicone Free)
• Compatible with EDILIANS PV modules

Installation
All tiles, fittings & accessories should be installed in accordance with the recommendations given in BS 5534: the British Standard Code of practice for slating & tiling. Sitework should be carried out in accordance with BS 8000-6: the British Standard for workmanship on building sites. Contact Edilians Technical Support for projects where the rafter length exceeds 6 metres.

Tile vent range
Our collection of vent tiles is available on our small, medium and large format clay and concrete roof tiles. The vents are manufactured to a high standard and are available in all colours and made to blend in discreetly with our existing roof tile product range, offering the perfect solution to roof space ventilation.

Colour options
Vent tiles are available in five standard colours to match your RDUK roof tiles:

• Brown
• Terracotta
• Antique Red
• Grey
• Anthracite

For further details contact our sales team or download the data sheet in our download section opposite.

Colours

Natural Red

Rustic Red

Burnt Red

Satin Black

Slate

Double Panne S Vent Tile
